Flight Operations to World Routes 2017 Barcelona: Network strategy will be up for discussion at the 23rd World Route Development Forum taking place in Barcelona this September 23-26. Here are the latest NOTAMs and operations details for El Prat.

El Prat Airport
  • IATA Code: BCN
  • ICAO Code: LEBL
  • Latitude/longitude: N41-17.8 / E002-04.7
  • Elevation: 14 FT / 4 M.
  • Operating hours: 24/7
  • Airport of entry
  • Time zone: UTC +1
  • Fuel: 100LL, Jet A1
Operational Information
  • Private flights require PRR slots
  • Private flights do not require overflight or landing permits
  • Non-scheduled commercial flights do not require overflight permits
  • Non-scheduled commercial flight require landing permits
  • Slot discrepancy winder +/-30 minutes for arrivals and +/-10 minutes for departures
  • Please notes that landing permits must be requested through AESA – the Spanish authority

Commercial Flights:

Air carriers from Non-EU/EAA member states may carry out the flight to/from the territory of Spain provided the operation of the scheduled flights has been authorized in accordance with a bilateral or multilateral agreement negotiated between Spain and the relevant state.

Please note that landing permits must be requested first from EASA and then from AESA for non-EU/EAA members.

It’s mandatory to have third country operator authorization (TCO authorization). EU member states reserve the right to deny the issuance of operating permits to TCO who cannot demonstrate they have applied to EASA for a TCO authorization.

NOTAMs

LEBL BARCELONA EL PRAT

A5720/17 – RAPID EXIT P6 TWY CL LIGHTS U/S. AVBL PPR 30 MIN. 13 SEP 06:00 2017 UNTIL 13 SEP 18:00 2017. CREATED: 08 SEP 10:37 2017

A5718/17 – RAPID EXIT TWY P6 INDICATION LIGHTS U/S. AVBL PPR 30 MIN. 13 SEP 06:00 2017 UNTIL 13 SEP 18:00 2017. CREATED: 08 SEP 10:16 2017

A5716/17 – RWY07L PAPI LIGHTS 50 PER CENT REDUCTION. AVBL PPR 30MIN. 13 SEP 06:00 2017 UNTIL 13 SEP 18:00 2017. CREATED: 08 SEP 09:55 2017

A5715/17 – RWY07L TDZ LIGHTS U/S. AVBL PPR 30 MIN. 13 SEP 06:00 2017 UNTIL 13 SEP 18:00 2017. CREATED: 08 SEP 09:41 2017

A5714/17 – 50 PER CENT RWY07L/25R EDGE LIGHTS U/S. AVBL PPR 30 MIN. 13 SEP 06:00 2017 UNTIL 13 SEP 18:00 2017. CREATED: 08 SEP 09:39 2017

A5713/17 – 50 PER CENT RCL LIGHTS RWY25R U/S. AVBL PPR 30 MIN. 13 SEP 06:00 2017 UNTIL 13 SEP 18:00 2017. CREATED: 08 SEP 09:26 2017

A5712/17 – 50 PER CENT RCL LIGHTS RWY07L U/S. AVBL PPR 30 MIN. 13 SEP 06:00 2017 UNTIL 13 SEP 18:00 2017. CREATED: 08 SEP 09:19 2017

A5711/17 – THR RWY25R LIGHTS U/S. AVBL PPR 30 MIN. 13 SEP 06:00 2017 UNTIL 13 SEP 18:00 2017. CREATED: 08 SEP 09:11 2017

A5710/17 – THR RWY07L LIGHTS U/S. AVBL PPR 30 MIN. 13 SEP 06:00 2017 UNTIL 13 SEP 18:00 2017. CREATED: 08 SEP 09:10 2017

A5709/17 – RWY25R END ID LIGHTS U/S. AVBL. PPR 30 MIN. 13 SEP 06:00 2017 UNTIL 13 SEP 18:00 2017. CREATED: 08 SEP 08:59 2017

A5708/17 – RWY07L APCH LIGHTING SYSTEM ALL CAT U/S. AVBL PPR 30MIN. 13 SEP 06:00 2017 UNTIL 13 SEP 18:00 2017. CREATED: 08 SEP 08:40 2017

A5699/17 – TWY K7 AND K11 CLSD. AVBL PPR 30 MIN. 12 SEP 23:00 2017 UNTIL 13 SEP 03:00 2017. CREATED: 07 SEP 14:59 2017

A5698/17 – RWY 07R/25L CLSD. AVBL PPR 30 MIN. 12 SEP 23:00 2017 UNTIL 13 SEP 03:00 2017. CREATED: 07 SEP 14:59 2017

A5697/17 – TWY M14, M13, BS AND GATE BS CLSD. AVBL PPR 30 MIN. 08 SEP 22:00 2017 UNTIL 09 SEP 04:00 2017. CREATED: 07 SEP 14:54 2017

A5680/17 – THR07L INDICATORS LIGHTS U/S. 06 SEP 09:58 2017 UNTIL 22 OCT 12:00 2017 ESTIMATED. CREATED: 06 SEP 09:58 2017

A5619/17 – REF SUP 39/17.-ACTIVATION OF LIGHTING SYSTEMS FOR RWY07L/25R:
PHASES 1 TO 3 AND 5 TO 32 COMPLETED. 01 SEP 07:55 2017 UNTIL 30 SEP 23:59 2017
ESTIMATED. CREATED: 01 SEP 07:56 2017

A5076/17 – TRIGGER NOTAM -PERM AIP AIRAC AMDT 09/17 WEF 14-SEP-17
SURFACE AND STRENGTH OF NEW TWY. RESA RWY 25R. REMARKS TO STRIP.

LOCAL REGULATIONS:
1) MINIMUM RUNWAY OCCUPANCY TIME.
2) UTILIZATION OF RAMP-0.
FORMAL EDITING.
ADC, PDC AND GMC CHARTS:
1) NEW DENOMINATION OF INNER TAXIWAYS ES1, FS1, GS1, HS1, LS1 AND
MS1.
2) INTERMEDIATE HOLDINGS POSITIONS IN RAMP- 16 AND 17, GATE LN, KN,
DN, CD AND TWY E3, ES1, FS1, GS1, HS1, LS1 AND MS1.
3) TAXIING DIRECTION IN TWY GN AND FN.
4) SUPPRESSION OF PRKG 123.
AIRCRAFT STANDS CHARACTERISTICS. 14 SEP 00:00 2017 UNTIL 27 SEP 23:59 2017.
CREATED: 03 AUG 07:22 2017

A4709/17 – TWY G2 STOPBAR CL LIGHTS U/S. AVBL PPR 30MIN. 14 SEP 08:00 2017 UNTIL 14 SEP 12:00 2017. CREATED: 14 JUL 13:47 2017

A4708/17 – TWY G1 STOPBAR CL LIGHTS U/S. AVBL PPR 30MIN. 14 SEP 08:00 2017 UNTIL 14 SEP 12:00 2017. CREATED: 14 JUL 13:46 2017

A4693/17 – RAPID EXIT TWY G5 INDICATOR LIGHTS U/S. AVBL PPR 30MIN. 15 SEP 08:00 2017 UNTIL 15 SEP 12:00 2017. CREATED: 14 JUL 12:40 2017

A4691/17 – CL LIGHTS TWY K2 U/S. AVBL PPR 30MIN. 14 SEP 08:00 2017 UNTIL 14 SEP 12:00 2017. CREATED: 14 JUL 12:06 2017

A4690/17 – CL LIGHTS TWY G3 U/S. AVBL PPR 30MIN. 14 SEP 08:00 2017 UNTIL 14 SEP 12:00 2017. CREATED: 14 JUL 12:04 2017

A4686/17 – RAPID EXIT ID LGT TWY G6 U/S. AVBL PPR 30MIN. 15 SEP 08:00 2017 UNTIL 15 SEP 12:00 2017. CREATED: 14 JUL 11:06 2017

A4684/17 – RAPID EXIT TWY G6 CL LIGHTS U/S. AVBL PPR 30MIN. 15 SEP 08:00 2017 UNTIL 15 SEP 12:00 2017. CREATED: 14 JUL 10:59 2017

A4677/17 – RAPID EXIT TWY G5 CL LIGHTS U/S. AVBL PPR 30MIN. 15 SEP 08:00 2017 UNTIL 15 SEP 12:00 2017. CREATED: 14 JUL 10:49 2017

A4676/17 – RAPID EXIT TWY G4 INDICATOR LGT U/S. AVBL PPR 30MIN. 15 SEP 08:00 2017 UNTIL 15 SEP 12:00 2017. CREATED: 14 JUL 10:49 2017

A4669/17 – RAPID EXIT TWY G4 CL LIGHTS U/S. AVBL PPR 30MIN. 15 SEP 08:00 2017 UNTIL 15 SEP 12:00 2017. CREATED: 14 JUL 10:29 2017

A4645/17 – RWY25L THR LGT 50 PER CENT U/S. AVBL PPR 30MIN. 13 SEP 08:00 2017 UNTIL 13 SEP 12:00 2017. CREATED: 13 JUL 14:24 2017

A4644/17 – 50 PER CENT REDUCTION INTENSITY PAPI LIGHTS RWY07R. AVBL PPR 30MIN. 13 SEP 08:00 2017 UNTIL 13 SEP 12:00 2017. CREATED: 13 JUL 13:45 2017

A4643/17 – 50 PER CENT REDUCTION INTENSITY PAPI LIGHTS RWY25L. AVBL PPR 30MIN. 13 SEP 08:00 2017 UNTIL 13 SEP 12:00 2017. CREATED: 13 JUL 13:44 2017

A4642/17 – 50 PERCENT NON INTRUSION STOP BAR G4, G5, G6, G7, G8, G9 U/S. AVBL
PPR 30 MIN. 13 SEP 08:00 2017 UNTIL 13 SEP 12:00 2017. CREATED: 13 JUL 13:30
2017

A4641/17 – 50 PERCENT STOPBAR LIGHTS G1, G2, G3, G10, G11, G12, K1, K6, K7,
K10, D1, D2, E1 AND E2 U/S. AVBL PPR 30MIN. 13 SEP 08:00 2017 UNTIL 13 SEP 12:00
2017. CREATED: 13 JUL 13:21 2017

A4640/17 – RWY25L CL LGT 50 PER CENT U/S. AVBL PPR 30 MIN. 12 SEP 08:00 2017 UNTIL 12 SEP 12:00 2017. CREATED: 13 JUL 13:13 2017

A4638/17 – RWY07R 50 PER CENT CL LGT U/S. AVBL PPR 30 MIN. 12 SEP 08:00 2017 UNTIL 12 SEP 12:00 2017. CREATED: 13 JUL 12:53 2017

E3501/17 – RWY25L ILS GP RESTRICTIONS:
POSSIBLE FLY-UP INDICATION AT 1600FT AMSL FROM 10NM 5DEG AT
RIGHT OF RCL. 30 JUN 08:20 2017 UNTIL 29 SEP 09:00 2017 ESTIMATED. CREATED:
30 JUN 08:21 2017

For more information on this event, visit http://www.routesonline.com/events/189/world-routes-2017/

For support with your Flight Operations to World Routes 2017 Barcelona, contact dxb@uas.aero
